Product Description
Details
The TM470R by Trackstar features the latest GPS and GSM technology that give increased tracking sensitivity and fast wireless communication anywhere in the world! It provides a range of connectivity including digital inputs, relay outputs and serial connections. Ruggedised, toughened outer casing, Thatcham Category 6, TQA391, complies to IP66 & IP67, offers integrated European cover in over 50 countries, Telenor Sim and battery monitoring.
What are the customer benefits?
- Ability to locate a vehicle real time to determine it is still on the site it was delivered to
- Hours capture to understand vehicle use and increase profitability and productivity
- Save on service costs with accurate hours used
- Ability to geofence your fleet to sites, generating alerts when a vehicle is moved to an alternative site/yard (when available)
- Access powerful tracking features with the Trackstar App for Android and iOS.
Technical Specification
- Ruggedised, toughened outer casing
- Telenor Sim
- Offers integrated European cover in over 50 countries
- 12Volt Negative Ground
- 3 x Wire connection, Permanent, Switched and ground
- Thatcham Category 6, TQA391
- Quiescent drain <2mA when in full sleep mode
- Complies to IP66 and IP67
- Dimensions approx. 155mm x 45mm x 102mm
- Quad Band GSM/GPRS global communications
- SIM-card or SIM IC
- Remote Configuration
- Non-destructive Over-The-Air software update
- 50-channel GPS module (GAL/LEO-ready), with
Super Sense (increased sensitivity) and Kick Start
(accelerated start up) - Motion sensing (3-Axis Accelerometer)
- Monitors vehicle 5 battery presence and voltage
Internal battery with intelligent fast charger featuring:
temperature sensing - battery condition monitoring
- RS232 external interface for peripheral connection
- 2 x Relay Drive Outputs with back EMF protection
- 4 x Digital inputs*
- Vehicle bus interface to SAE )1708 (RS485)*
- Vehicle bus interface to SAE )1939 (CANj*
- Secondary RS232 interface*
- HD Lithium-Ion battery back up
- Internal antenna*
(*optional features)
