VTT5000 Fleet Trailer Tracking

The reporting interval can be set to suit a customer's specific requirements, providing a compelling combination of mobility, longevity and adaptability. Superior GPS performance allows the unit to be installed in secure locations on assets out of sight.

The VTT5000 is state-of-the-art trailer tracking system. The system has a rechargeable battery and is connected to a power supply of the trailer when the trailer is connected.

The system lays dormant and only waking up from deep sleep mode at regular intervals to give a precise location of your asset with no interaction or intervention. The system also wakes up when there is movement and starts sending locations at 1 minute intervals until a period that the vehicle is stationary and the movement has stopped. In doing this, you have a system that can be used to locate where a trailer has been left and also, one that will give a real-time tracked journey.

Features

• Daily trailer locations.
• Real-time journey tracking on movement.
• 30 day battery life on 1 hour locations.
• 2 hour battery recharge.
• 12 month subscription.
• Low battery notification.
• Network Jamming Detection

Web Portal

The intuitive web portal offers a platform to see all of your trailers in one location. You can see the whole fleet or individual trailers. Key features are location, history, journey playback, geofences, speed and direction.

The advanced Event Engine allows you to create a notification if your asset moves into or out of any number of locations. These locations are completely in your control and can be created, edited and deleted using our simple map interface in the web platform.

Specification

Internal Battery Pack

• 5,000mAh Li-Ion cell battery 3.7V

Mounting

• Screw, adhesive or bolt mount

Location technology

• A-GPS with internal antenna
• (-161 dBm tracking sensitivity)

Environmental range

• -40˚C to +85˚C
• IP-67 rated housing
• Vibration tested
• Network Jamming Detection

Power Consumption

• Transmitting 200mA
• Normal 70 ~ 90 mA
• Idle 2 ~ 4 mA
• Sleep 0.1 ~ 0.4 mA

Communication technology

• EDGE/GPRS packet data
• Fail-over to SMS in poor signal
• 868 MHz RF-beacon

Battery Technology

• Lithium thionyl chloride
• Field replaceable packs

Weight

• 310 Grams

Size

• 108x92x32 mm
